Model: Diamond 1024 console LS-K010
Series: Stage light console
Scan Website QR code
Learn more by cell phone
力盛舞台灯光
Parameters
Demonstration
Video

DMX512 channel number 1024

Matching number of computer lights 96

Computer lights re-matching address code support

Lighting horizontal and vertical exchange support

Lamp channel output support instead

Lighting channel slide mode switch support

Each scanner can use up to 40 main channels + 40 fine-tuning channels

Light Bank Support Pearl R20 Light Bank

Number of scenes that can be saved 60

Number of scenes that can be run at the same time

The total number of steps in a multi-step scene 600

Time control fade in the scene, fade, LTP slide

Each scene can store the number of graphics 5

Putter to start the scene and dimming support

Interlock scene support

Control scene support

Graphics Builder generates Dimmer, P / T, RGB, CMY, Color, Gobo, Iris, Focus graphics

Can run the number of graphics 5

Master putter global, repeat, lighting

Blackrock immediately support

Dial adjustment channel numerical support

Fader adjustment channel numerical support

Pusher dimming support

U disk read support FAT32 format

Size: 485mmx420mmx105mm
