Technical Parameters

Voltage: 110V-240V; 50 / 60HZ;

Light Source: Imported OSRAM 350W light source

Channel mode: 16 international standard DMX512 channel, master-slave mode.

Horizontal scan: 540 degrees (160bit precision scan) Electronic error correction.

Vertical scanning: 270 degrees (160bit precision scanning) Electronic error correction.

Optical lens: 3-in-one high-precision optical lens.

Focusing: Electronic focusing 3 meters to infinity

Atomization: 0-100% linear atomization

Prism: built-in Shuangling mirror and colorful honeycomb prism

Color film tray: 14 color film + white light, with a rotating rainbow effect, full color and half-color go two modes to switch.

Gobo: 17 fixed gobo or 4-6 glass patterns

Strobe: Double-sided knife strobe rate up to 13 times per second, and may choose to random strobe and strobe pulse.

Display: color touch screen

Size: length 320 * width 290 * height 640MM
